Dell PowerEdge R760xs Rack Server | Dual Xeon Gold 6448Y | 32GB DDR5 | 480GB SSD | PERC H755 | 2U | Dual 1100W | 3Yr ProSupport

The Dell PowerEdge R760xs is a powerful 2U rack mounted enterprise server designed to support high performance computing, virtualization environments and enterprise applications. Built on the Intel Xeon Scalable platform, the R760xs delivers exceptional processing power, DDR5 memory performance and scalable storage options suitable for modern data center infrastructures.

This configuration is powered by dual Intel Xeon Gold 6448Y processors, each offering 32 cores and 64 threads with a base frequency of 2.1GHz and a large 60MB cache. With two high performance processors installed, the server delivers outstanding multi core performance for demanding workloads such as virtualization clusters, database systems, analytics platforms and enterprise application hosting.

The system includes 32GB DDR5 RDIMM ECC memory (2 × 16GB) running at 5600 MT/s, providing significantly improved memory bandwidth and efficiency compared with previous server generations. ECC technology automatically detects and corrects memory errors, ensuring stable system operation and protecting mission critical workloads.

For storage, the server includes a 480GB SATA read intensive enterprise SSD installed in a 2.5 inch drive mounted in a 3.5 inch hybrid hot plug carrier. This configuration provides fast system boot times and reliable storage performance for operating systems and enterprise applications. The 3.5 inch chassis supports up to 8 SAS or SATA drives, allowing organizations to expand storage capacity as infrastructure needs grow.

Storage performance and redundancy are handled by the PERC H755 SAS RAID controller, which supports RAID levels 0, 1 and 5 to improve storage performance and ensure data protection.

Networking connectivity is provided through the Broadcom 5720 dual port 1GbE onboard network adapter, delivering reliable connectivity for enterprise infrastructure environments.

System administrators can monitor and manage the server using Dell iDRAC9 Enterprise, enabling advanced remote management capabilities such as lifecycle management, system monitoring and firmware updates without requiring physical access to the hardware.

Power reliability is ensured through dual 1100W Titanium hot plug redundant power supplies (1+1 configuration), allowing the server to continue operating even if one power supply fails. The system also includes high performance cooling fans to maintain optimal thermal performance under heavy workloads.

The server includes ReadyRails sliding rails for secure rack installation and is backed by Dell 3 Year ProSupport, ensuring enterprise grade technical support and service coverage.

Key Specifications

Model: Dell PowerEdge R760xs

Form Factor: 2U Rack Server (3.5 Inch 8 Bay chassis)

Processors: 2 × Intel Xeon Gold 6448Y (32C / 64T each)

Memory: 32GB DDR5 RDIMM ECC (2 × 16GB, 5600 MT/s)

Storage: 1 × 480GB SATA SSD (Read Intensive, Hot Plug)

Drive Bays: Up to 8 × 3.5″ SAS/SATA drives

RAID Controller: PERC H755 SAS Front

Networking: Broadcom 5720 Dual Port 1GbE Onboard

Remote Management: iDRAC9 Enterprise

Cooling: High performance fan set (x5)

Power Supply: Dual 1100W Titanium Hot Plug PSUs (1+1 redundancy)

Rails: ReadyRails sliding rails (no cable management arm)

Warranty: 3 Year Dell ProSupport
