Dell PowerEdge R760xs | Xeon Silver 4514Y | 32GB | 8TB SAS | PERC H755 | 12×3.5″” | Quad 1GbE | Dual 1100W | 3Yr ProSupport

The Dell PowerEdge R760xs is a powerful 2U rack server designed for enterprise workloads, virtualization environments and high capacity storage deployments. Built on the latest Intel Xeon Scalable architecture, the R760xs delivers reliable processing performance, flexible storage expansion and advanced lifecycle management capabilities for modern data centers.

This configuration is powered by the Intel Xeon Silver 4514Y processor, providing strong enterprise compute performance with Intel Turbo Boost and Hyper Threading technology. The processor is well suited for virtualization platforms, business applications, analytics workloads and infrastructure services.

The server includes 32GB DDR5 RDIMM ECC memory running at 5600 MT/s, offering higher bandwidth and improved efficiency compared with previous server generations. ECC memory automatically detects and corrects memory errors, ensuring stable system performance and protecting critical data.

For storage, the system includes an 8TB SAS enterprise hard drive (3.5″ hot plug) designed for reliable performance in data intensive environments. The 3.5 inch chassis supports up to 12 SAS or SATA drives, allowing organizations to expand storage capacity for large datasets, backup environments and virtualization workloads.

Storage performance and data protection are managed by the PERC H755 SAS RAID controller, supporting RAID levels 0, 1 and 5 to improve storage performance and provide redundancy.

Networking connectivity is provided through the Broadcom 5720 quad port 1GbE BASE-T OCP NIC, along with the Broadcom 5720 dual port 1Gb onboard LOM, delivering flexible network connectivity for enterprise infrastructures.

System administrators can monitor and manage the server through iDRAC9 Enterprise (16G), Dell’s advanced remote management platform that enables lifecycle management, firmware updates and remote diagnostics without requiring physical access to the system.

Power reliability is ensured through dual redundant 1100W Titanium hot plug power supplies (1+1 configuration), ensuring continuous operation even if one power supply fails. The server also includes rack rails and a standard front bezel for secure installation in rack environments.

Backed by Dell 3 Year ProSupport, the PowerEdge R760xs provides enterprise grade reliability, scalability and performance for organizations running mission critical workloads.

Key Specifications

Model: Dell PowerEdge R760xs

Form Factor: 2U Rack Server

Processor: Intel Xeon Silver 4514Y

Memory: 32GB DDR5 RDIMM ECC (5600 MT/s)

Storage: 1 × 8TB SAS 3.5″ Hot Plug Drive

Drive Bays: Up to 12 × 3.5″ SAS/SATA drives

RAID Controller: PERC H755 SAS Front (RAID 0/1/5)

Networking:

Broadcom 5720 Dual Port 1Gb On Board LOM

Broadcom 5720 Quad Port 1GbE BASE-T OCP NIC 3.0

Management: iDRAC9 Enterprise (16G)

Expansion: PCIe slots (1×16 + 1×8)

Power Supply: Dual 1100W Titanium Hot Plug PSUs (1+1 redundancy)

Rails: Rack rails with front bezel

Warranty: 3 Year Dell ProSupport
